## Scientists Solve Most Complex Traveling Salesman Problem Ever

See how they cracked the deceptively simple—but brutally tough—problem for 22 "cities." • The traveling salesman is an age-old exercise in optimization , studied in school and relevant to "real life."
• Rearranging how data feeds through the processor allows more than one thread to compute at a time.

Scientists in Japan have solved a more complex traveling salesman problem than ever before. The previous standard for instant solving was 16 “cities,” and these scientists have used a new kind of processor to solve 22 cities. They say it would have taken a traditional von Neumann CPU 1,200 years to do the same task.

The traveling salesman problem is centuries old, and it asks a deceptively simple question: For a salesman with a map of, say, 10 cities with given distances apart and roads connecting them, what’s the shortest path for the salesman to travel to every city and return home? The “deceptive” part is that the math to support the problem quickly grows overwhelmingly complex.

Each leg of the journey has a different length. Not all the cities connect to each other to form an ideal full star topology. And segments that connect, say, five cities have to somehow be compared to segments that connect three or eight. It’s just too variable, in both the proverbial and literal senses. A computer processor must calculate one full route at a time while storing the order of the points touched and the length of each leg of the journey. ## More From Popular Mechanics The problem combines graph theory (the “map” of points with weighted legs between them) with combinatorics (the different ways you can count through a graph, in this case) and optimization (choosing the best, shortest route from a given graph). Because of this robust subject appeal, it’s been a favorite exercise in math and computer science classes of all kinds for many, many years.

The secret to these researchers’ success with the traveling salesman problem is in the special circuit they designed to calculate the routes. In a traditional computer processor, the routes must be arranged and then calculated and all passed through the processor one point at a time—the system is linear.

In most computing applications, we don’t notice that processing happens this way because the calculations are so rapid that they basically appear simultaneous. But the traveling salesman problem clogs the works because the number of calculations required is so huge. Adding more points on the map only increases the complexity. (Honestly, this news itself underlines how complicated the problem is: It’s major news to be able to solve just 22 cities instead of just 16!)

The researchers took a traditional circuit architecture and changed one critical thing: They rearranged special “spin cells” representing all the graph points so that the spin cells could all communicate with each other, not just the immediate surroundings connected by lines on the graph. This new arrangement allows routes to be made using multiple points at a time instead of just one, with fewer bottlenecks in the computational process.

The potential applications of a more powerful salesman solver are myriad. The abstract problem is infamous because it’s so widely studied and difficult, but its roots are still as an abstraction of a real person’s dilemma: How do I do my job the most efficient way? Every day, taxi and Uber drivers must consider the best route to find the most passengers. Delivery drivers must arrange their addresses in an efficient way. And these applications don’t just involve minimizing distance—fresh food or the value of a fare add even more complexity.

Suddenly, the 22nd address on the route is going to receive a much hotter pizza. Caroline Delbert is a writer, avid reader, and contributing editor at Pop Mech. She's also an enthusiast of just about everything. Her favorite topics include nuclear energy, cosmology, math of everyday things, and the philosophy of it all. Fairy Circles Are More Widespread Than We Thought The U.S. Wants a Working Fusion Reactor By 2035 Murder Maps of Medieval England Cities Released Trees Rings Reveal a New Seismic Threat to Seattle You’ll Never Live Forever—Blame Physics Found: Human Genetic Populations Once Thought Lost Tiny Sea Creature Sheds Evolutionary Light Archaeologists Discover a Brand New Language What to Know About the Military Sleep Technique How to Mine the Largest Lithium Deposit on Earth A Fifth Ocean May Be Forming, Scientists Say

• DSA for Beginners
• DSA Tutorial
• Data Structures
• Dynamic Programming
• Binary Tree
• Binary Search Tree
• Divide & Conquer
• Mathematical
• Backtracking
• Branch and Bound
• Pattern Searching
• Write an Interview Experience
• Hamiltonian Cycle
• Number of Hamiltonian cycle
• Hamiltonian Path ( Using Dynamic Programming )
• Proof that Hamiltonian Cycle is NP-Complete
• Print all Hamiltonian Cycles in an Undirected Graph
• Proof that Hamiltonian Path is NP-Complete

## Traveling Salesman Problem (TSP) Implementation

• Permutation of numbers such that sum of two consecutive numbers is a perfect square
• Discuss(20+)

Travelling Salesman Problem (TSP) : Given a set of cities and distances between every pair of cities, the problem is to find the shortest possible route that visits every city exactly once and returns to the starting point.  Note the difference between Hamiltonian Cycle and TSP. The Hamiltonian cycle problem is to find if there exists a tour that visits every city exactly once. Here we know that Hamiltonian Tour exists (because the graph is complete) and in fact, many such tours exist, the problem is to find a minimum weight Hamiltonian Cycle.  For example, consider the graph shown in the figure on the right side. A TSP tour in the graph is 1-2-4-3-1. The cost of the tour is 10+25+30+15 which is 80. The problem is a famous NP-hard problem. There is no polynomial-time known solution for this problem.

Examples:

In this post, the implementation of a simple solution is discussed.

• Consider city 1 as the starting and ending point. Since the route is cyclic, we can consider any point as a starting point.
• Generate all (n-1)! permutations of cities.
• Calculate the cost of every permutation and keep track of the minimum cost permutation.
• Return the permutation with minimum cost.

Below is the implementation of the above idea

Time complexity:  O(n!) where n is the number of vertices in the graph. This is because the algorithm uses the next_permutation function which generates all the possible permutations of the vertex set.  Auxiliary Space: O(n) as we are using a vector to store all the vertices.

Improve your coding skills with practice.

## Traveling salesman problem

This web page is a duplicate of https://optimization.mccormick.northwestern.edu/index.php/Traveling_salesman_problems

Author: Jessica Yu (ChE 345 Spring 2014)

Steward: Dajun Yue, Fengqi You

The traveling salesman problem (TSP) is a widely studied combinatorial optimization problem, which, given a set of cities and a cost to travel from one city to another, seeks to identify the tour that will allow a salesman to visit each city only once, starting and ending in the same city, at the minimum cost. 1

• 2.1 Graph Theory
• 2.2 Classifications of the TSP
• 2.3 Variations of the TSP
• 3.1 aTSP ILP Formulation
• 3.2 sTSP ILP Formulation
• 4.1 Exact algorithms
• 4.2.1 Tour construction procedures
• 4.2.2 Tour improvement procedures
• 5 Applications
• 7 References The origins of the traveling salesman problem are obscure; it is mentioned in an 1832 manual for traveling salesman, which included example tours of 45 German cities but gave no mathematical consideration. 2 W. R. Hamilton and Thomas Kirkman devised mathematical formulations of the problem in the 1800s. 2

It is believed that the general form was first studied by Karl Menger in Vienna and Harvard in the 1930s. 2,3

Hassler Whitney, who was working on his Ph.D. research at Harvard when Menger was a visiting lecturer, is believed to have posed the problem of finding the shortest route between the 48 states of the United States during either his 1931-1932 or 1934 seminar talks. 2 There is also uncertainty surrounding the individual who coined the name “traveling salesman problem” for Whitney’s problem. 2

The problem became increasingly popular in the 1950s and 1960s. Notably, George Dantzig, Delber R. Fulkerson, and Selmer M. Johnson at the RAND Corporation in Santa Monica, California solved the 48 state problem by formulating it as a linear programming problem. 2 The methods described in the paper set the foundation for future work in combinatorial optimization, especially highlighting the importance of cutting planes. 2,4

In the early 1970s, the concept of P vs. NP problems created buzz in the theoretical computer science community. In 1972, Richard Karp demonstrated that the Hamiltonian cycle problem was NP-complete, implying that the traveling salesman problem was NP-hard. 4

Increasingly sophisticated codes led to rapid increases in the sizes of the traveling salesman problems solved. Dantzig, Fulkerson, and Johnson had solved a 48 city instance of the problem in 1954. 5 Martin Grötechel more than doubled this 23 years later, solving a 120 city instance in 1977. 5 Enoch Crowder and Manfred W. Padberg again more than doubled this in just 3 years, with a 318 city solution. 5

In 1987, rapid improvements were made, culminating in a 2,392 city solution by Padberg and Giovanni Rinaldi. In the following two decades, David L. Appelgate, Robert E. Bixby, Vasek Chvátal, & William J. Cook led the cutting edge, solving a 7,397 city instance in 1994 up to the current largest solved problem of 24,978 cities in 2004. 5

## Description

Graph theory. In the context of the traveling salesman problem, the verticies correspond to cities and the edges correspond to the path between those cities. When modeled as a complete graph, paths that do not exist between cities can be modeled as edges of very large cost without loss of generality. 6 Minimizing the sum of the costs for Hamiltonian cycle is equivalent to identifying the shortest path in which each city is visiting only once.

## Classifications of the TSP

The TRP can be divided into two classes depending on the nature of the cost matrix. 3,6 • Applies when the distance between cities is the same in both directions • Applies when there are differences in distances (e.g. one-way streets)

An ATSP can be formulated as an STSP by doubling the number of nodes. 6

## Variations of the TSP  ## Formulation The objective function is then given by To ensure that the result is a valid tour, several contraints must be added. 1,3 There are several other formulations for the subtour elimnation contraint, including circuit packing contraints, MTZ constraints, and network flow constraints.

## aTSP ILP Formulation

The integer linear programming formulation for an aTSP is given by ## sTSP ILP Formulation

The symmetric case is a special case of the asymmetric case and the above formulation is valid. 3, 6 The integer linear programming formulation for an sTSP is given by ## Exact algorithms Branch-and-bound algorithms are commonly used to find solutions for TSPs. 7 The ILP is first relaxed and solved as an LP using the Simplex method, then feasibility is regained by enumeration of the integer variables. 7

Other exact solution methods include the cutting plane method and branch-and-cut. 8

## Heuristic algorithms

Given that the TSP is an NP-hard problem, heuristic algorithms are commonly used to give a approximate solutions that are good, though not necessarily optimal. The algorithms do not guarantee an optimal solution, but gives near-optimal solutions in reasonable computational time. 3 The Held-Karp lower bound can be calculated and used to judge the performance of a heuristic algorithm. 3

There are two general heuristic classifications 7 :

• Tour construction procedures where a solution is gradually built by adding a new vertex at each step
• Tour improvement procedures where a feasbile solution is improved upon by performing various exchanges

The best methods tend to be composite algorithms that combine these features. 7

## Tour construction procedures ## Tour improvement procedures ## Applications

The importance of the traveling salesman problem is two fold. First its ubiquity as a platform for the study of general methods than can then be applied to a variety of other discrete optimization problems. 5 Second is its diverse range of applications, in fields including mathematics, computer science, genetics, and engineering. 5,6 Suppose a Northwestern student, who lives in Foster-Walker , has to accomplish the following tasks:

• Drop off a homework set at Tech
• Work out a SPAC
• Complete a group project at Annenberg

Distances between buildings can be found using Google Maps. Note that there is particularly strong western wind and walking east takes 1.5 times as long.

It is the middle of winter and the student wants to spend the least possible time walking. Determine the path the student should take in order to minimize walking time, starting and ending at Foster-Walker.

Method 1: Complete Enumeration

All possible paths are considered and the path of least cost is the optimal solution. Note that this method is only feasible given the small size of the problem.

From inspection, we see that Path 4 is the shortest. So, the student should walk 2.28 miles in the following order: Foster-Walker → Annenberg → SPAC → Tech → Foster-Walker

Method 2: Nearest neighbor

Starting from Foster-Walker, the next building is simply the closest building that has not yet been visited. With only four nodes, this can be done by inspection:

• Smallest distance is from Foster-Walker is to Annenberg
• Smallest distance from Annenberg is to Tech
• Smallest distance from Tech is to Annenberg ( creates a subtour, therefore skip )
• Next smallest distance from Tech is to Foster-Walker ( creates a subtour, therefore skip )
• Next smallest distance from Tech is to SPAC
• Smallest distance from SPAC is to Annenberg ( creates a subtour, therefore skip )
• Next smallest distance from SPAC is to Tech ( creates a subtour, therefore skip )
• Next smallest distance from SPAC is to Foster-Walker

So, the student would walk 2.54 miles in the following order: Foster-Walker → Annenberg → Tech → SPAC → Foster-Walker

Method 3: Greedy

With this method, the shortest paths that do not create a subtour are selected until a complete tour is created.

• Smallest distance is Annenberg → Tech
• Next smallest is SPAC → Annenberg
• Next smallest is Tech → Annenberg ( creates a subtour, therefore skip )
• Next smallest is Anneberg → Foster-Walker ( creates a subtour, therefore skip )
• Next smallest is SPAC → Tech ( creates a subtour, therefore skip )
• Next smallest is Tech → Foster-Walker
• Next smallest is Annenberg → SPAC ( creates a subtour, therefore skip )
• Next smallest is Foster-Walker → Annenberg ( creates a subtour, therefore skip )
• Next smallest is Tech → SPAC ( creates a subtour, therefore skip )
• Next smallest is Foster-Walker → Tech ( creates a subtour, therefore skip )
• Next smallest is SPAC → Foster-Walker ( creates a subtour, therefore skip )
• Next smallest is Foster-Walker → SPAC

So, the student would walk 2.40 miles in the following order: Foster-Walker → SPAC → Annenberg → Tech → Foster-Walker As we can see in the figure to the right, the heuristic methods did not give the optimal solution. That is not to say that heuristics can never give the optimal solution, just that it is not guaranteed.

Both the optimal and the nearest neighbor algorithms suggest that Annenberg is the optimal first building to visit. However, the optimal solution then goes to SPAC, while both heuristic methods suggest Tech. This is in part due to the large cost of SPAC → Foster-Walker. The heuristic algorithms cannot take this future cost into account, and therefore fall into that local optimum.

We note that the nearest neighbor and greedy algorithms give solutions that are 11.4% and 5.3%, respectively, above the optimal solution. In the scale of this problem, this corresponds to fractions of a mile. We also note that neither heuristic gave the worst case result, Foster-Walker → SPAC → Tech → Annenberg → Foster-Walker.

Only tour building heuristics were used. Combined with a tour improvement algorithm (such as 2-opt or simulated annealing), we imagine that we may be able to locate solutions that are closer to the optimum.

The exact algorithm used was complete enumeration, but we note that this is impractical even for 7 nodes (6! or 720 different possibilities). Commonly, the problem would be formulated and solved as an ILP to obtain exact solutions.
